CAPABILITIES

  • Designed to counter Remote Piloted Aircraft Systems (RPAS)
  • Mitigation of control, video and navigation signals.
  • Fully mobile
  • All modules are integrated and ready to be used by activating trigger
  • Equipment is ready to be used with one push of a button (power on)
  • System is provided with all required power supply equipment, cables etc.
  • Battery operation time – up to one hour
  • Changeable batteries
  • Installed battery charge module allows to charge batteries while operating
  • Additional (spare) batteries available
  • Equipment can operate on 2 different power supplies
  1. Integrated DC battery.
  2. AC/DC adapter

SPECIFICATION

Description Specs

Size (cm)

Length - 90  Hight - 35   Width - 25

Weight (kg)
6kg
Battery Type
Integrated DC rechargeable battery
Effective Range
3000 m
Duty Cycle
Supports 100% continuous operation
Jamming Frequencies
WiFi 2,4 GHz ,5,8 GHz • GPS 1,5 GHz * • GNSS 1,5 GHz *
Antenna
• 2,4 GHz directional antenna • GPS/GNSS 1,5 GHz – 2x directional antennas • 5.8 GHz directional antenna
Battery operation time
up to one hour
Temperature
-20 to + 40C operating temp. -40 to +85 C storage range
